      BB90 Bottom Bracket Trek SRAM GXP

      Trek developed their own bb standard to optimize their frame designs.
      BB90 has a 90.5mm shell width and 37mm inner diameter and is designed so that the bearings of external cups can hide within the frame.

      The CeramicSpeed kit comes as two bearings, which are then pressed into the frame. Those two bearings consist of either CeramicSpeed Standard or Coated Bearings. Both feature super smooth, super round CeramicSpeed balls rotating in hardened-steel races.

      The Coated version has a metallic coating laid onto the races, making it even smoother and harder, resulting in longer life and lower drag.

      In The Box

      • 1 24mm BB90 bearing
      • 1 22mm BB90 bearing for GXP.
      • 2 seals.
      • 1 integrated 24mm dust cover.
      • 1 metal GXP dust cover
      • Wavy washer + spacers
      • All Round Grease.
      • Sticker Sheet.

    1 1

CERAMICSPEED

BB90 Bottom Bracket Trek SRAM GXP

SKU:

R 5,499.00
R 5,499.00
Sale Sold out
Tax included.
Size
×

BB90 Bottom Bracket Trek SRAM GXP

SKU Size Color STOCK
101375 SRAM GXP 24 / 22,2mm Standard Arrives in 7 days
Color
Standard
*Product will arrive 7-10 days from order
View full details

Trek developed their own bb standard to optimize their frame designs.
BB90 has a 90.5mm shell width and 37mm inner diameter and is designed so that the bearings of external cups can hide within the frame.

The CeramicSpeed kit comes as two bearings, which are then pressed into...

×

BB90 Bottom Bracket Trek SRAM GXP

Trek developed their own bb standard to optimize their frame designs.
BB90 has a 90.5mm shell width and 37mm inner diameter and is designed so that the bearings of external cups can hide within the frame.

The CeramicSpeed kit comes as two bearings, which are then pressed into the frame. Those two bearings consist of either CeramicSpeed Standard or Coated Bearings. Both feature super smooth, super round CeramicSpeed balls rotating in hardened-steel races.

The Coated version has a metallic coating laid onto the races, making it even smoother and harder, resulting in longer life and lower drag.

In The Box

  • 1 24mm BB90 bearing
  • 1 22mm BB90 bearing for GXP.
  • 2 seals.
  • 1 integrated 24mm dust cover.
  • 1 metal GXP dust cover
  • Wavy washer + spacers
  • All Round Grease.
  • Sticker Sheet.

TECHNICAL SPECIFICATIONS

The BB90 standard is limited to Trek. This kit makes it possible for 24/22mm thru-axle cranks from Quarq and SRAM to mate with your Trek.

The Standard Bearings last at least 3 times longer than other bearings. That’s a result of hardened-steel races and ceramic balls that are 100% smoother & 15% harder than the ceramic competition. These bearings have a frictional drag of 0.3-0.4 watts per set, which boasts an average 75% drag reduction compared to stock bb’s.

The Coated Bearings increase bearing life by 60% and reduce drag by 50% compared to Standard Bearings.

To better modify the performance for your needs, consider the grease you’re using. All Round Grease comes installed, but can be changed for lower drag Race Day Grease, or higher durability Long Life Grease, which adds a bit of drag but stays in when riding through messy conditions.

INSTALLATION

Installation of BB90 Bottom Bracket for Trek SRAM GXP

If you don't have any experience installing bottom brackets and bearings, we recommend that you have your local bike shop fit your new bearings. Find your nearest retailer.



Installation of SRAM GXP cranks on CeramicSpeed Bottom Brackets

MAINTENANCE

We recommend that you follow our instructions on how to maintain your CeramicSpeed Bottom Brackets to achieve the lowest friction and the best longevity.
